PERIODIC MAINTENANCE 2-21
Periodic Maintenance Procedures
Bolts and Nuts Tightening
Tightness Inspection
•
Check the tightness of the bolts and nuts listed here in
accordance with the Periodic Maintenance Chart. Also,
check to see that each cotter pin is in place and in good
condition.
If there are loose fasteners, retorque them to the speci-
fied torque following the specified tightening sequence.
Refer to the appropriate chapter for torque specifications.
If torque specifications are not listed in the appropriate
chapter, see the Basic Torque Table (see Torque and
Locking Agent). For each fastener, first loosen it by 1/2
turn, then tighten it.
If cotter pins are damaged, replace them with new ones.
Bolts, Nuts, and Fasteners to be checked
Wheels:
Front Axle Nuts and Cotter Pins
Rear Axle Nuts and Cotter Pins
Wheel Nuts
Brakes:
Brake Lever Pivot Bolt
Brake Lever Pivot Nut
Brake Pedal Cotter Pin
Steering/Suspension:
Handlebar Clamp Bolts
Stem Clamp Allen Bolts
Stem Bearing Housing Bolts
Ti e-Rod End Nuts and Cotter Pins
Ti e-Rod Adjusting Sleeve Locknuts
Shock Absorber Mounting Bolts and Nuts
Suspension Arm Pivot Bolts
Steering Knuckle Pivots Nuts and Cotter Pins
Engine:
Engine Mounting B olts
Engine Mounting Bracket Bolts
Exhaust Pipe Holder Nuts
Muffler Mounting Bolts
Muffler Clamp Bolt
Others:
Footrest Mounting Bolts
Throttle Mounting Bolts
Carrier Mounting Bolts
