GENERAL INFORMATION 1-7
General Specifications
Item KLF250-A1 ∼ A3
Drive Train
Primary Reduction System:
Type Gear
Reduction Ratio 3.450 (69/20)
Clutch Type Wet multi disc and centrifugal
Transmission:
Type 5-speed plus reverse, constant mesh, return shift
Gear Ratio: 1st 2.923 (38/13)
2nd 1.684 (32/19)
3rd 1.173 (27/23)
4th
0.923 (24/26)
5th 0.785 (22/28)
Reverse 3.115 (27/13 × 33/22)
Final Drive System:
Type Shaft
Reduction Ratio 4.680 (18/15 × 39/10)
Overall Drive Ratio (@Top Gear)
12.686
Final Gear Case Oil:
Type Hypoid gear oil
SAE90 (above 5°C, 41°F) or
SAE80 (below 5°C, 41°F)
Capacity 0.2L(0.21USqt)
Frame
Type Double tubular
Caster (Rake Angle) 4.0°
Camber 3.0°
King Pin Angle 10°
Trail 17 mm (0.67 in.)
Tread:
Front 764 mm (30.08 in.)
Rear 776 mm (30.55 in.)
Front Tire:
Type Tubeless
Size AT21 × 8 - 9
Rear Tire:
Type Tubeless
Size AT22 × 10 - 10
Suspension:
Front:
Type Independent swing axle
Wheel Travel
115 mm (4.53 in.)
Rear:
Type Torque tube-link
Wheel Travel 125 mm (4.92 in.)
