FINAL DRIVE 11-3
Exploded View
Torque
No. Fastener N·m kgf·m ft·lb Remarks
1 Output Bevel Gear Case Bolts (M8) 25 2.5 18 L(1)
2 Output Bevel Gear Case Bolts (M6) 8.8 0.9 78 in·lb
3 Oil Seal Housing Nuts 25 2.5 18
4
Output Drive Gear Nut
118 12 87
MO
5 Cam Damper Mounting Nut 78 8.0 58 MO
6 Driven Gear Shaft Nut 147 15 108 L
7 Bearing Retainers 108 11 80 L
8 Pinion Gear Nut 69 7.0 51 St
9 Propeller Shaft Housing Nuts 25 2.5 18
G: Apply grease for oil seal and O-ring.
L: Apply a non-permanent locking agent.
M: Apply molybdenum disulfide grease.
MO: Apply molybdenum disulfide oil.
St: Stake the fasteners to prevent loosening.
