FINAL DRIVE 11-13
Output Bevel Gear Case
Drive Gear Shims
Thickness Part Number
0.15 mm (0. 006 in.)
92025-1573
0.20 mm (0. 008 in.) 92025-1574
0.7 mm (0.028 in .)
92025-1534
0.8 mm (0.031 in .)
92025-1535
0.9 mm (0.035 in .)
92025-1536
1.0 mm (0.039 in.) (primary) 92025-1537
1.1 mm (0.043 in .)
92025-1575
1.2 mm (0.047 in .)
92025-1538
1.3 mm (0.051 in .)
92025-1533
Driven Bevel Gear Shims
Thickness (mm)
Part Number
0.10 mm (0. 004 in.)
92025-1859
0.15 mm (0. 006 in.)
92025-1860
0.50 mm (0. 020 in.)
92025-1861
0.80 mm (0. 031 in.)
92025-1862
1.00 mm (0 .039 in.) (primary )
92025-1858
1.20 mm (0. 047 in.)
92025-1863
Bevel Gear Backlash Adjustment
•
Clean any dirt and oil off the bevel gear teeth.
•
Install the output drive gear with the primary shim (see the
shim tables).
•
Apply molybdenum disulfide oil to the seating surface and
threads of the output drive gear nut and tighten it.
Torque - Output Drive Gear Nut: 118 N·m (12 kgf·m, 87 ft·lb)
•
Install the driven gear with the primary shim (see the shim
tables).
•
Temporarily install the output bevel gear case on the
crankcase, and tighten the case bolts.
○
Be sure to install the case gasket.
○
Do not install the following part.
Oil Seal Holder
Torque - Output Bevel Gear Case Bolts (M8): 25 N·m (2.5
kgf·m, 18 ft·lb)
Output Bevel Gear Case Bolts (M6): 8.8 N·m (0.9
kgf·m, 78 in·lb)
•
Check the backlash during the tightening of the case bolts
and stop tightening them immediately if the backlash dis-
appears. Then, change the shim to a thinner one.
