7-4 ENGINE LUBRICATION SYSTEM
Specifications
Item Standard
Engine Oil
Type API SF or SG
API SH or SJ with JASO MA
Viscosity SAE 10W-40
Capacity 2.0 L (2.11 US qt) (when filter is not removed)
2.1 L (2.22 US qt) (when filter is removed)
2.75 L (2.91 US qt) (when engine is completely dry)
