Kawasaki WORKHORSE 250 (2003) [269/322] Electrical system 16 13
![Kawasaki WORKHORSE 250 (2003) [269/322] Electrical system 16 13](/views2/1121215/page269/bg10d.png)
ELECTRICAL SYSTEM 16-13
Battery
Initial Charging
WARNING
Keep the battery away from sparks and open flames
during charging, since the battery gives off a n ex-
plosive gas mixture of hydrogen and oxygen.
When using a battery charger, connect the battery
to the charger before turning on the charger. This
procedure prevents sparks at the battery terminals
which could ignite any battery gases.
•
Fill each cell to the upper level line on the battery case with
fresh electrolyte (specific gravity: 1.270) at a temperature
of 30°C (86°F) or less. Let the battery stand for about 30
minutes before charging.
NOTE
○
If the electrolyte level drops, add electrolyte to the upper
level line before charging.
•
Set the charging rate at 1/10 the battery capacity, and
charge it for 10 hours. For example, if the battery is
rated at 14 Ah, 11 Ah (U.S. m odel), the charging rate
would be 1.4 Ah, 1.1 Ah (U.S. model).
CAUTION
If the battery is not given a full initial charging, it
will discharge in a few weeks. After that it can not
be charged by supplemental charging.
Always remove the battery from the vehicle for
charging. If the battery is charged while still in-
stalled, battery electrolyte may spill and corrode
the frame or other parts of the vehicle.
Do not use a high rate battery charger, as is typi-
cally employed at automotive service stations, un-
less the charger rate can be reduced to the level re-
quired. Charging the battery at a rate higher than
specified may ruin the battery. Charging at a high
rate causes excess heat which can warp the plates
and cause internal shorting. Higher-than-normal
charging rates also cause the plates to shed active
material. Deposits will accumulate, and can cause
internal shorting.
If the temperature of the electrolyte rises above 45°
C (113°F) during charging, reduce the charging rate
to lower the temperature, and increase charging
time proportionately.
•
Turn the charger off, then disconnect it from the battery.
•
Check:
Electrolyte Level (see Electrolyte Level Inspection)
Battery Voltage
○
Battery voltage should be 12.6 V or more.
