2-4 PERIODIC MAINTENANCE
Torque and Locking Agent
Torque
Fastener
N·m kgf·m ft·lb
Remarks
Clutch Spring Bolts
12 1.2 104 in·lb
Primary Clutch Hub Nut 127 13 94 MO
Secondary Clutch Hub Nut 78 8.0 58 MO
Balancer Drive Gear Nut 83 8.5 61 MO
Balancer Gear Nut 118 12 87 MO
Clutch Adjusting Screw Locknut 11 1.1 95 in·lb
Recoil Starter
Recoil Starter Mounting Bolts 8.8 0.9 78 in·lb
Recoil Starter Flange Nut 12 1.2 104 in·lb
Engine Lubrication System
Oil Pipe Banjo Bolts 15 1.5 11
Oil Pump Screws 4.4 0.45 39 in·lb
Engine Drain Plug 29 3.0 22
Oil Filter Cover Bolts 8.8 0.9 78 in·lb
Relief Valve 15 1.5 11 L
Engine Removal/Installation
Engine Bracket Bolts and Nuts 26 2.7 20
Engine Mounting Nuts (M10) 39 4.0 29
Engine Mounting Nut (M8)
29 3.0 22
Crankshaft/Transmission
Engine Drain Plug 29 3.0 22
Crankcase Bolts
8.8 0.9 78 in·lb
Clutch Release Cam Pin 25 2.5 18 L
Return Spring Pin 25 2.5 18 L
Output Shaft Bearing Position Plate Screws 8.8 0.9 78 in·lb L
Relief Valve 15 1.5 11 L
Bearing Stopper Screws 9.8 1.0 87 in·lb
Positioning Lever Bolt 8.8 0.9 78 in·lb
Neutral and Reverse Switch Screws – – – L
Shift Drum Pin Plate Bolt 12 1.2 104 in·lb
Wheels/Tires
Wheel Nuts 34 3.5 25 S
Rear Axle Nut 147 15 108
Final Drive
Output Bevel Gear Case Bolts (M8) 25 2.5 18 L(1)
Output Bevel Gear Case Bolts (M6) 8.8 0.9 78 in·lb
Oil Seal Housing Nuts
25 2.5 18
Drive Gear Nut 118 12 87 MO
Cam Damper Mounting Nut 78 8.0 58 MO
Driven Gear Shaft Nut 147 15 108 L
Bearing Retainer 108 11 80 L
Pinion Gear Nut 69 7.0 51 St
Propeller Shaft Housing Nuts 25 2.5 18
