ELECTRICAL SYSTEM 16-3
Exploded View
Torque
No. Fastener N·m kgf·m ft·lb Remarks
1 Alternator Cover Bolts 8.8 0.9 78 in·lb
2 Spark Plug 14 1.4 10
3 Starter Motor Clutch Bolts 34 3.5 25 L
4
Ignition Switch Nut
2.9 0.3 26 in·lb
5 Alternator Rotor Bolt 59 6.0 43
6: Other than U.S.A. Model
7: U.S.A. Model
8: U.S.A., Canada and Australia Models
9: Europe and United Kingdom Models
A: KLF250-A1
B: KLF250-A2 ∼
Gr: Apply grease.
MO: Apply molybdenum disulfide oil.
SS: Apply silicone sealant (Kawasaki Bond: 56019-120).
