ENGINE TOP END 4-3
Exploded View
Torque
No. Fastener N·m kgf·m ft·lb Remarks
1 Cylinder Head Bolts (M10), first torque 13 1.3 113 in·lb L(1), MO, S
1 Cylinder Head Bolts (M10), final toque 34 3.5 25 S
2 Cylinder Head Bolts (M6), first torque 5.9 0.6 52 in·lb MO, S
2
Cylinder Head Bolts (M6), final torque
9.8 1.0 87 in·lb
S
3 Valve Adjusting Cap Bolts 8.8 0.9 78 in·lb
4 Retaining Bolt 4.4 0.45 39 in·lb
5
Compression Releasing Lever Bolt
8.8 0.9 78 in·lb
G: Apply grease for oil seal and O-ring.
L: Apply a non-permanent locking agent.
MO: Apply molybdenum disulfide oil.
R: Replacement Parts
S: Follow the specific tightening sequence.
