3-4 FUEL SYSTEM

Specifications

Standard

Item

KLF250-A1 KLF250-A2 ∼

Service Limit

Throttle Case and Cable

Throttle Lever Free Play 2 ∼ 3 mm (0.08 ∼ 0.12 in.) –––

Carburetor

Make/Type MIKUNI VM24SS –––

Main Jet #115 #120 –––

Main Air Jet 1.0 1.8 –––

Needle Jet O-6M O-2M –––

Jet Needle 5GN64-1 5GN74-1 –––

Pilot Jet #30 #22.5 –––

Pilot Air Jet 1.3 1.0 –––

Pilot Screw 1 1/2 turns out 2 1/2 turns out –––

Starter Jet #45 –––

Idle Speed 1 300 ∼ 1 400 r/min (rpm)

–––

Service Fuel Level 5 ± 1 mm (0.20 ± 0.04 in.) –––

below bottom edge of

carburetor body

Float Height 22.6 ± 2 mm (0.89 ± 0.04 in.) –––

Optional Parts:

Main Jet:

Altitude:

0 ∼ 500 m (0 ∼ 1 600 ft) #115 #120 –––

(92063-1109) (92063-1106)

500 ∼ 1 500 m (1 600 ∼ 4 900 ft) #112.5 #117.5 –––

(92063-1110) (92063-1107)

1 500 ∼ 2 500 m (4 900 ∼ 8 200 ft) #110 #115 –––

(92063-1038) (92063-1109)

2500∼ 3 500 m (8 200 ∼ 11 500 ft) #107.5 #112.5 –––

(92063-073) (92063-1110)

3 500 ∼ 4 500 m (11 500 ∼ 14 800 ft) #102.5 #110 –––

(92063-1028) (92063-1038)

Air Cleaner

Air cleaner element oil High-quality foam air filter oil –––
