FUEL SYSTEM 3-15
Carburetor
Carburetor Cleaning
WARNING
Clean the carburetor in a well-ventilated area, and
take care that there is no spark or flame anywhere
near the working area; this includes any appliance
with a pilot light. Because of the danger of highly
flammable liquids, do not use gasoline or low-flash
point solvents to clean the carburetor. A fire or ex-
plosion could result.
CAUTION
Do not use compressed air on an assembled carbu-
retor, the float may be crushed by the pressure, and
the vacuum piston diaphragm may be damaged.
Remove as many rubber or plastic parts from the
carburetor as possible before cleaning t he carbure-
tor with a cleaning solution. This will prevent dam-
age or deterioration of the parts.
The carburetor body has plastic parts that cannot
be removed. DO NOT use a strong carburetor
cleaning solution which could attack these parts,
instead, use a mild high-flash point cleaning solu-
tion safe for plastic parts.
•
Disassemble the carburetor (see Carburetor Disassem-
bly).
•
Immerse all the metal parts in a carburetor cleaning solu-
tion.
•
Rinse the parts in water.
•
When the parts are clean, dry them with compressed air.
•
Blow the air and fuel passages with compressed air.
•
Assemble the carburetor (see Carburetor Assembly).
Carburetor Inspection
WARNING
Gasoline is extremely flammable and can be ex-
plosive under certain conditions. Turn the ignition
switch OFF. Do not smoke. Make sure the area is
well ventilated and free from any source of flame
or sparks; this includes any appliance with a pilot
light.
•
Before removing the carburetor, check the fuel level (see
Fuel Level Inspection).
If the fuel level is incorrect, inspect the rest of the c arbu-
retor before correcting it.
