5-12 ENGINE RIGHT SIDE
Clutches
Clutch Spring Free Length Measurement
If any of the springs [A] is shorter than the service limit, it
must be replaced.
Clutch Spring Free length
Standard: 37.2 mm (1.46 in.)
Service Limit: 35.7 mm (1.41 in.)
