GENERAL INFORMATION 1-9
Unit Conversion Table
Prefixes for Units:
Prefix Symbol Power
mega M ×1000000
kilo k × 1 000
centi c ×0.01
milli m × 0.001
micro µ × 0.000001
Units of Mass:
kg ×2.205=lb
g × 0.03527 = oz
Units of Volume:
L × 0.2642 =
gal (US)
L × 0.2200 =
gal (imp)
L × 1.057 = qt (US)
L × 0.8799 = qt (imp)
L × 2.113 = pint (US)
L × 1.816 =
pint (imp)
mL × 0.03381 =
oz (US)
mL × 0.02816 =
oz (imp)
mL × 0.06102 = cu in.
Units of Force:
N × 0.1020 = kg
N × 0.2248 = lb
kg ×9.807=N
kg ×2.205=lb
Units of Length:
km × 0.6214 = mile
m × 3.281 = ft
mm × 0.03937 = in
Units of Torque:
N·m × 0.1020 = kgf·m
N·m × 0.7376 = ft·lb
N·m × 8.851 = in·lb
kgf·m × 9.807 = N·m
kgf·m
×7.233=
ft·lb
kgf·m
× 86.80 = in·lb
Units of Pressure:
kPa × 0.01020 =
kg/cm²
kPa × 0.1450 = psi
kPa × 0.7501 = cmHg
kg/cm²
× 98.07 = kPa
kg/cm² × 14.22 = psi
cm Hg × 1.333 = kPa
Units of Speed:
km/h × 0.6214 = mph
Units of Power:
kW × 1.360 =
PS
kW × 1.341 = HP
PS × 0.7355 = kW
PS × 0.9863 = HP
Units of Temperature:
