ConfiguringandViewingDevicePortInformation

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page106

D‐LinkUWSUserManual

PortSummary

UsethePortSummarypagetoviewthesettingsforallphysicalportsontheplatform.

ToaccessthePortSummarypage,clickLAN>Monitoring>PortUtilizationinthenavigationmenu.

ThetableonthePortSummarypagedoesnotfitononescreen.Usethescrollbarattheb

ottomofthebrowser

toviewallthecolumnsonthepage.Figure40showsthefirstsixrowsofallthecolumnsonthepage.Although

thetableissplitintothreeseparateimagesinthefigure,thecolumnsarecontinuehorizontallyacrossthepage.

Figure40:PortSummary

Table33:Po

rtSummaryFields

Field Description

MSTID IfSpanningTreeProtocolisenabledontheswitch,youcanselecttheMultiple

SpanningTreeinstanceIDfromthelistofallcurrentlyconfiguredMSTID'sto

determinethevaluesdisplayedfortheSpanningTreeparameters.Changing

theselectedMSTIDwillgenerateascreenrefresh.IfSTPisdisable

d,whichis

thedefault,theMSTIDfieldshowsthestaticvalue“CST”insteadofamenu.

Slot/Port Identifiestheportthattheinformationintherestoftherowisassociated

with.

PortType Formostportsthisfieldisblank.Otherwise,thepossiblevaluesare:

• Mirrored:Indicatesthattheportha

sbeenconfiguredasamonitoringport

andisthesourceportinaportmirroringsession.

• Probe:Indicatesthattheporthasbeenconfiguredasamonitoringport

andisthedestinationportinaportmirroringsession.Formore

informationaboutportmonitoringandprobeports,see“MultiplePo

rt

Mirroring”onpage86.

• PortChannel:Indicatesthattheporthasbeenconfiguredasamemberof

aport‐channel,whichisalsoknownasalinkAggregationGroup(LAG).For

informationaboutconfiguringportchannels,see“CreatingPortChannels

(Trunking)”onpage204.

STPMode ShowstheSp

anningTreeProtocol(STP)AdministrativeModefortheportor

LAG,whichcanbeEnabledorDisabled.FormoreinformationaboutSTP,see

“ConfiguringSpanningTreeProtocol”onpage238.
