D-Link DWS-4026 [346/741] Diffserv service summary

ConfiguringDifferentiatedServices

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page346

D‐LinkUWSUserManual

DiffServServiceSummary

TheDiffServServi ceSummarypageprovidesanoverviewofthepolicies‐portassociations.Todisplaythepage,

clickLAN>Monitoring>DifferentiatedServices>ServiceSummaryinthenavigationmenu.

Figure235:ServiceSummary

ServiceStatistics

UsetheServiceStatisticspagetodisplayservice‐levelstatisticalinformationaboutallinterfacesthathave

DiffServpoliciesattached.

Todisplaythepage,clickLAN>Monitoring>DifferentiatedServices>ServiceStatisticsinthenavigation

menu.

Figure236:ServiceStatistics

Table208:ServiceStatisticsFields

Field Description

CounterModeSelector Usethemenutodeterminetheformatofthedisplayedcountervalues,which

mustbeeitherOctetsorPackets.ThedefaultisOctets.

ServiceStatistics

Interface Showstheinterfaceforwhichservicestatisticsaretodisplay.

Direction Showsthedirectionofpacketsforwhichservicestatisticsdisplay.
