LocatingWLANDevices

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page648

D‐LinkUWSUserManual

ThefollowingtableshowsthefieldsavailableontheClientTriangulationSummarypage.

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

DetailedAPTriangulationStatus

UsetheClientTriangulationStatuspagetoviewdetailedtriangulationandlocationinformationabouta

detectedormanagedwirelessclient.Toviewdetailedtriangulationinformationforaspecificclient,selectits

MACaddressfromtheavailablemenu.

Figure419:DetailedClientTriangulationStatus

Table381:ClientTriangulationSummary

Field Description

DeviceMACAddress MACaddressofthewirelessclient.

DeviceType IndicateswhetherthedeviceisanAssociatedClientoraDetected

Client.Ifthetypeofdevicechanges,thechangemightnotbereflected

untilthedevicelocationisnextcomputed.

Building/FloorNumber Numberthatidentifiesthebuildingandfloorwherethedeviceis

det

ected.Avalueof0indicatesthatnodataisavailable.

DetectedXYCoordinate IdentifiestheXandYaxisoffsetsofthewirelessclientfromsome

arbitrary0,0pointonthebuildingfloor.

Status Thestatusofthelastiterationofthelocationcomputationalgorithm:

•NotExecuted

•Success

•Failure
