ConfiguringAccessControlLists

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page351

D‐LinkUWSUserManual

Section7:ConfiguringAccessControlLists

AccessControlLists(ACLs)ensurethatonlyauthorizedusershaveaccesstospecificresourceswhileblocking

offanyunwarrantedattemptstoreachnetworkresources.ACLsareusedtoprovidetrafficflowcontrol,restrict

contentsofroutingupdates,decidewhichtypesoftrafficareforwardedorblocked,andaboveallprovide

securityfo

rthenetwork.D‐LinkDWS‐4000SeriessoftwaresupportsIPv4andMACACLs.Thetotalnumberof

MACandIPACLssupportedbyD‐LinkDWS‐4000Seriessoftwareis100.

TheAccessControlListsfoldercontainslinkstothefollowingfoldersandwebpages:

• “ConfiguringIPAccessControlLists”

• “M

ACAccessContr olLists”

• “ACLInterfaceConfiguration”

YoufirstcreateanIPv4‐basedorMAC‐basedruleandassignauniqueACLID.Then,youdefinetherules,which

canidentifyprotocols,sourceanddestinationIPandMACaddresses,andotherpacket‐matchingcriteria.

Finally,youusetheIDnumbertoas

signtheACLtoaport.

ConfiguringIPAccessControlLists

IPaccesscontrollists(ACL)allownetworkmanagerstodefineclassificationactionsandrulesforspecificports.

ACLsarecomposedofaccesscontrolentries(ACE),orrules,thatconsistofthefiltersthatdeterminetraffic

classifications.ThetotalnumberofrulesthatcanbedefinedforeachACLis12.Theserule

sarematched

sequentiallyagainstapacket.Whenapacketmeetsthematchcriteriaofarule,thespecifiedruleaction

(Permit/Deny)istaken,includingdroppingthepacketordisablingtheport,andtheadditionalrulesarenot

checkedforamatch.Forexample,anetworkadministratordefinesanACLruletha

tsaysportnumber20can

receiveTCPpackets.Howev er,ifaUDPpacketisreceivedthepacketisdropped.

ToconfigureanACL:

1. Usethe“IPACLConfiguration”pagetodefinetheIPACLtypeandassignanIDtoit.

2. Usethe“IPACLRuleConfiguration”pagetocr

eaterulesfortheACL.

3. Usethe“ACLInterfaceConfiguration”pagetoassigntheACLbyitsIDnumbertoaport.
