D‐LinkUWSUserManual

PortSummary

UsethePortAccessControlPortSummarypagetoviewsummaryinformationabouttheportaccesscontrol

settingsonallphysicalports.

ToaccessthePortBasedAccessControlPortSummarypage,clickSecurity>PortBasedAccessControl>Port

Summaryinthenavigationmenu.

Figure298:PortAccessControlPortSu

mmary

SessionTerminationAction DisplaystheTerminationActionsetbytheRADIUSServerfortheselected

port.Possiblevaluesare:

•Default

• Reauthenticate

IftheterminationactionisDefaultthen,attheendofthesession,theclient

detailsareinitialized.Otherwise,re‐authenticationisattempted.

Note:Thisfieldisdisplayedonlywhentheportcont

rolmodeoftheselected

portisnotMAC‐based.

LogicalPort Displaysthelogicalportnumberassociatedwiththesupplicantthatis

connectedtotheport.Thisfieldisnotconfigurable.

Note:Thisfieldisdisplayedwhentheportcontrolmodeoftheselectedport

isMAC‐based.

SupplicantMacAddress Thisfielddis

playsthesupplicant’sMACaddressthatisconnectedtotheport.

Thisfieldisnotconfigurable.

Note:Thisfieldisdisplayedwhentheportcontrolmodeoftheselectedport

isMAC‐based.

Table250:PortAccessControlStatusFields(Cont.)

Field Description
