D-Link DWS-4026 [476/741] Viewing distributed tunneling statistics

MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page476

D‐LinkUWSUserManual

ViewingDistributedTunnelingStatistics

Thedistributedtunnelingstatisticsshowinformationaboutthenumberofpacketsandbytestransmittedand

receivedbyclientsthatuseL2distributedtunnelsonanaccesspointmanagedbytheswitch.

UsethemenuabovethetabletoselecttheAPwiththesettingstoview.TheAPisidentifiedbyitsMA

Caddress

andlocation.

Table283describesthefieldsyouseeontheDistributedTunnelingStatisticspageforthemanagedaccess

pointstatistics.

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

Table283:ManagedAccessPointDistributedTunnelingStatistics

Field Description

BytesTransmitted TotalbytestransmittedviaalldistributedtunnelsbytheAP.

BytesReceived TotalbytesreceivedviaalldistributedtunnelsbytheAP.

MulticastPacketsTransmitted TotalmulticastpacketstransmittedviaalldistributedtunnelsbytheAP.

MulticastPacketsReceived TotalmulticastpacketsreceivedviaalldistributedtunnelsbytheAP.

PacketsTransmitted Totalpac

ketstransmittedviaalldistributedtunnelsbytheAP.

PacketsReceived TotalpacketsreceivedviaalldistributedtunnelsbytheAP.

TotalRoamedClientsofAP NumberofClientsthatusedthisAPfordistributedtunneling.Thecount

includeclientsthatroamedawayandroamedtothisAP.

RoamedClientsIdleTimedOut Numb

erofClientsthatroamedawayfromthisAPandweretimedoutdue

tonotsendingtrafficonthetunnel.

RoamedClientsAgeTimedOut NumberofClientsthatroamedawayfromthisAPandweretimedoutdue

toageofthetunnel.

ClientLimitDenials NumberoftimestheAPden

iedtheclientsattempttosetupadistributed

tunnelduetotheAPreachingtheconfiguredtunneledclientlimit.

ClientMaxReplicationDenials NumberoftimestheAPdeniedtheclientsattempttosetupadistributed

tunnelduetotheAPreachingtheconfiguredmaximumnumberofVLAN

replications.
