Protocol‐BasedVLANSummary

UsetheProtocol‐basedVLANSummarypagetoviewinformationaboutprotocol‐basedVLANgroups

configuredonthesystem.

ToaccesstheProtocol‐basedVLANSummarypage,clickLAN>Monitoring >VLANSummary>Protocol‐based

VLANPortSummaryinthenavigationtree.

Figure102:Protocol‐basedVLANSummary

•ClickRefreshtore

loadthepageanddisplaythemostcurrentinformation.

Table86:Protocol‐basedVLANSummaryFields

Field Description

GroupName Showstheuser‐definednameassociatedwithprotocolgroup.

GroupID Showsthenumberthatidentifiesthegroupyoucreate.GroupIDsare

automaticallyassignedwhenyoucreateagroup.

Protocols Showstheprotocolkeywordorprotocolvalue(hexordecimalnumbers)to

associatewiththisgroup,whichcanbeoneormor

eofthefollowing:

VLAN SpecifiestheVLANIDassociatedwiththisgroup.

Interface Showstheinterfacesparticipatinginthisgroup.
