VLANRouting

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page316

D‐LinkUWSUserManual

Figure208showsthepagewhenatleastoneVLANroutinginterfacehasbeencreated.

Figure209:VLANRoutingConfiguration‐InterfaceExists

CreatingaVLANRoutingInterface

1. EnteranewVLANIDintheVLANIDfield.

2. ClickCreate.

ThepagerefreshesanddisplaystheinterfaceandMACaddressassignedtothenewVLAN.Theinterface

isinSlot/Portnotation.TheIPaddressandSubnetMaskfieldsare0.0.0.0.

3. Inthenavigationmenu,clickLAN>L3Features>IP>InterfaceCo

nfiguration.

4. SelecttheinterfaceassignedtotheVLAN.

TheIPaddressandSubnetMaskfieldsare0.0.0.0bydefault.

Table188:VLANRoutingConfigurationFields

Field Description

VLANID EntertheIDofaVLANtoconfigureforVLANRouting.Initially,thefieldwilldisplaytheID

ofthefirstVLAN.AfteryouenteranewVLANIDandclickCreate,thenon‐configurable

datawillbedisplayed.

Interface ThelogicalslotandportnumberassignedtotheVLANRoutingIn

terface.

MACAddress TheMACAddressassignedtotheVLANRoutingInterface.

IPAddress TheconfiguredIPAddressoftheVLANRoutingInterface.NotethatifaVLANiscreated

andtheIPaddressisnotconfigured,thepagebydefaultshowsanIPaddressof0.0.0.0.

ToconfiguretheIPaddress,gotoLAN>L3Features>Routing>IP>Interface

nfiguration.IntheInterfacefieldontheIPInterfaceConfigurationpage,selectthe

interfaceidentifiedintheInterfacefield(e.g.4/1)ontheVLANRoutingConfiguration

page.

SubnetMask TheconfiguredSubnetMaskoftheVLANRoutingInterface.Thisis0.0.0.0whentheVLAN

utingInterfaceisfirstconfiguredandmustbeenteredontheIPInterfaceConfiguration

page.

Note:BesuretonotetheinterfaceSlot/Portassignmentsothatyouselectthecorrectinterfaceto

configurefromtheInterfaceConfigurationpage.
