PortAccessControl

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page426

D‐LinkUWSUserManual

PortAccessControlStatistics

UsethePortAccessControlStatisticspagetoviewEAPandEAPOLinformationonaspecific port.

ToaccessthePortBasedAccessControlStatisticspage,clickSecurity>PortBasedAccessControl>Statistics

inthenavigationmenu.

Figure299:PortAccessControlStatis tics

Table252:PortAccessControlStatisticsFields

Field Description

Interface Selectstheporttobedisplayed.Whentheselectionischanged,ascreen

refreshwilloccurcausingallfieldstobeupdatedforthenewlyselectedport.

Allphysicalinterfacesarevalid.

EAPOLFramesReceived DisplaysthenumberofvalidEAPOLframesreceivedontheport.

EAPOLFramesTransmitted DisplaysthenumberofEA

POLframestransmittedviatheport.

EAPOLStartFramesReceived DisplaysthenumberofEAPOLStartframesreceivedontheport.

EAPOLLogoffFrames

Received

DisplaysthenumberofEAPOLLogoffframesthathavebeenreceivedonthe

port.

LastEAPOLFramesVersion Displaysthepr otocolversionnumberattachedtothemostre

centlyreceived

EAPOLframe.

LastEAPOLFramesSource DisplaysthesourceMACAddressattachedtothemostrecentlyreceived

EAPOLframe.

EAPResponse/IDFrames

Received

DisplaysthenumberofEAPRespondIDframesthathavebeenreceivedonthe

port.

EAPResponseFrames

Received

DisplaysthenumberofvalidEAPRespondframesreceivedontheport.
