•Ifyoumakeanychangestothepage,clickSubmittoapplythechangestothesystem.Ifyoucreateanew

Community,itisaddedtothetablebelowtheSubmitbutton.

•ClickDeletetodeletetheselectedSNMPCommunity.

TrapReceiverConfiguration

UsetheTrapReceiverConfigurationpagetoconfigureinformationabouttheSNMPcommunityandthetrap

managerthatwillreceiveitstrappackets.

ToaccesstheTrapReceiverConfigurationpage,clickLAN>Administration>SNMPManager>TrapReceiver

Configurationfromthenavigationtree.

Figure54:TrapReceiverConfiguration

ClientIPMask AlongwiththeClientIPAddress,theClientIPMaskde

notesarangeofIP

addressesfromwhichSNMPclientsmayusethatcommunitytoaccessthis

device.

AccessMode Specifytheaccesslevelforthiscommunity:

• Read‐Only:TheCommunityhasreadonlyaccesstotheMIBobjects

configuredinth

eview.

• Read‐Write:TheCommunityhasread/modifyaccesstotheMIBobjects

configuredintheview.

Status Specifythestatusofthiscommunity:

• Enable:Thecommunityisenabled,andtheCommunityNamemustbe

uniqueamongallvalidCommunityNamesorthesetrequestwillbe

rejected.

• Disable:TheCommunityisdisable

dandtheCommunityNamebecomes

invalid.

Table43:CommunityConfigurationFields(Cont.)

Field Description
