ConfiguringMLDSnooping

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page227

D‐LinkUWSUserManual

MulticastRouterVLANConfiguration

UsetheMLDSnoopingMulticastRouterVLANConfigurationpagetoconfiguremulticastroutersettingsfor

VLANsonaninterface.

ToaccesstheMLDSnoopingMulticastRouterVLANConfigurationpage,clickLAN>L2Features >MLD

Snooping>MulticastRouterVLANConfigurationinthenavigationtree.

Figure138:MulticastRouterVLANConfiguration

•Ifyo

uenableordisablemulticastrouterconfigurationforVLANsonaninterface,clickSubmittoapplythe

newsettingstotheswitch.

Table120:MulticastRouterVLANConfigurationFields

Field Description

Slot/Port Selectthephysical,VLAN,orLAGinterfacetodisplay.

VLANID EntertheVLANIDtoconfigureasenabledordisabledformulticastrouting.

MulticastRouter SelectEnableorDisablefromthedrop‐downmenutochangethemulticast

routermodeoftheVLANassociatedwiththisinterface.
