MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page500

D‐LinkUWSUserManual

SwitchAssociatedClientStatus

TheWLAN>Monitoring>Client>AssociatedClients>SwitchStatustabdisplaystheSwitchAssociatedClient

StatuspagewhichshowsinformationabouttheswitchthatmanagestheAPtowhichtheclientisassociated.

Figure334:SwitchAssociatedClientStatus

TodisconnectaclientfromanAP,selecttheboxne

xttotheswitchIPaddress,andthenclickDisassociate.

CommandButtons

Thepageincludesthefollowingbuttons:

• Disassociate—DisassociatestheclientfromthemanagedAP.

• Refresh—Updatesthepagewiththelatestinformation.

Table300:SwitchAssociatedClientStatus

Field Description

SwitchIPAddress ShowstheIPaddressoftheswitchthatmanagestheAPtowhichtheclientis

associated.

ClientMACAddress ShowstheMACaddressoftheassociatedclient.
