TACACS+ServerConfiguration

UsetheTACACS+ServerConfigurationpagetoconfigureuptofiveTACACS+serverswithwhichtheswitchcan

communicate.

TodisplaytheTACACS+ServerConfigurationpage,clickLAN>Security>TACACS+>ServerConfigurationin

thenavigationmenu.

Figure303showstheTACACS+AccountingServerConfigurationpagewhennoTACACS+serversar

econfigured

orwhenyouselectAddfromtheTACACS+Serverfield.

Figure303:TACACS+Configuration—NoServer

AfteryouaddoneormoreTACACS+servers,additionalfieldsappearontheTACACS+ServerConfiguration

page.

•ClickRefreshtoupdatethepagewiththemostcurrentinformation.

•Ifyoumakechangestothepage,clickSubm

ittoapplythechangestothesystem.

•TodeleteaconfiguredTACACS+server,selecttheIPaddressoftheserverfromtheRADIUSServerIP

Addressdrop‐downmenu,andthenclickRemove.

Table256:TACACS+ConfigurationFields

Field Description

TACACS+Server Usethedrop‐downmenutoselecttheIPaddressoftheTACACS+serverto

vieworconfigure.IffewerthanfiveTACACS+serversareconfiguredonthe

system,theAddoptionisalsoavailable.SelectAddtoconfigureadditional

TACACS+servers.

IPAddress EntertheIPaddressoftheTACACS+ser

vertoadd.Thisfieldisonlyavailable

whenAddisselectedintheTACACS+Serverfield.

Port TheauthenticationportnumberthroughwhichtheTACACS+sessionoccurs.

Thedefaultisport49,andtherangeis0‐65535.

KeyString DefinestheauthenticationandencryptionkeyforTACACS+communications

betweenthedeviceandtheTA

CACS+server.Thiskeymustmatchthe

encryptionusedontheTACACS+server.Thevalidrangeis0‐128characters.

ConnectionTimeout Theamountoftimethatpassesbef oretheconnectionbetweenthedevice

andtheTACACS+servertimesout.Thefieldrangeisfrom1to30seconds.
