MulticastRouterStatus

UsetheIGMPSnoopingMulticastRouterStatuspagetoseewhetheraparticularinterfaceisconfiguredasa

multicastrouterinterface.

ToaccesstheIGMPSnoopingMulticastRouterStatisticspage,clickMonitoring >IGMPSnoopingStatus>

MulticastRouterStatusinthenavigationtree.

Figure125:MulticastRouterStatus

•ClickRefreshtore‐displa

ythepagewiththelatestinformationfromtherouter.

Table107:MulticastRouterStatusFields

Field Description

Slot/Port SelectthephysicalorLAGinterfacetodisplay.

MulticastRouter Showswhetherthespecifiedinterfaceisconfiguredasamulticastrouter

interface.
