ViewingAssociatedClientVAPStatus

EachAPhas16VirtualAccessPoints(VAPs)perradio,andeveryVAPhasauniqueMACaddress(BSSID).The

WLAN>Monitoring>Client>AssociatedClients>VAPStatustabdisplaystheVAPAssociatedClientStatus

pagewhichshowsinformationabouttheVAPsonthemanagedAPthathaveas

sociatedwirelessclients.To

disconnectaclientfromanAP,selecttheboxnexttotheBSSID,andthenclickDisassociate.

Figure333:VAPAssociatedClientStatus

CommandButtons

Thepageincludesthefollowingbuttons:

• Disassociate—DisassociatestheclientfromthemanagedAP.

• Refresh—Updatesthepagewiththelatestinformation.

Table299:VA

PAssociatedClientStatus

Field Description

BSSID IndicatestheEthernetMACaddressforthemanagedAPVAPwherethisclientis

associated.

SSID IndicatestheSSIDforthemanagedAPVAPwherethisclientisassociated.

APMACAddress ThisfieldindicatesthebaseAPEthernetMACaddressforthemanagedAP.

Location ThedescriptivelocationconfiguredforthemanagedAP

Radio DisplaysthemanagedAPradiointerfacetheclientisassociatedtoanditsconfigured

mode.

ClientMACAddress TheEthernetaddressoftheclientstation.

ClientIPAddress TheIPaddressoftheclientstation.
