PortDetailed

ThePortDetailedpagedisplaysavarietyofper‐porttrafficstatistics.

ToaccessthePortDetailedpage,clickLAN>Monitoring>SystemStatistics>PortDetailedinthenavigation

tree.

Figure81showssome,butnotall,ofthefieldsonthePortDetailedpage.

Figure81:PortDetailed

Table71:Det

ailedPortStatisticsFields

Field Description

Slot/Port Usethedrop‐downmenutoselecttheinterfaceforwhichdataistobe

displayedorconfigured.

ifIndex ThisfieldindicatestheifIndexoftheinterfacetableentryassociatedwiththis

portonanadapter.

MediaType ThetypeofphysicalmediumfortheEthernet.Thepossiblevaluesar e10Base‐

T,100Base‐TX,10

0Base‐FX,1000Base‐X,1000Base‐Tand10GBase‐X.

ARPType Encapsulationtypeforthenetworkaddress.ThevalueisalwaysARPA.

PacketsRXandTX64Octets Thetotalnumberofpack ets(includingbadpackets)receivedortransmitted

thatwere64octetsinlength(excludingframingbitsbutincludingFCSo

ctets).
