D-Link DWS-4026 [341/741] Policy configuration

ConfiguringDifferentiatedServices

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page341

D‐LinkUWSUserManual

PolicyConfiguration

UsethePolicyConfigurationpagetoassociateacollectionofclasseswithoneormorepolicystatements.

Todisplaythepage,clickLAN>QoS>DifferentiatedServices>PolicyConfigurationinthenavigationmenu.

ThefieldsavailableonthePolicyConfigurationpagedependonwhetheryoucreateanewclassorc

onfigurea

classthathasalreadybeencreated.

Figure229showsthePolicyConfiguration pagewhenthePolicySelectoroptionisCreate.

Figure229:PolicyConfiguration

Figure230showsthePolicyConfigurationpagewhenthePolicySelectoroptionshowsaconfiguredpolicythat

hasamemberclass.Toconfigureamembercla

ss,see“ClassConfiguration”onpage338.

Figure230:PolicyConfiguration

Table205:PolicyConfigurationFields

Field Description

PolicySelector Tocreateanewpolicy,selectCreate fromthemenu;anotherpageappearsto

facilitatecreationofanewpolicy.Tochangeapolicynameortomodifythe

classlistmembers,selectthepolicynamefromthemenu.Todeletean

existingpolicyselectitfromthemenu,andthencl

ickDelete.

PolicyName IfyouselectCreatefromthePolicySelectormenu,enteranametoassociate

withtheclass(es).Thenameisacase‐sensitivealphanumericstringfrom1to

31charactersuniquelyidentifyingapolicy.Tomodifythenameofanexisting

policy,selectitfromtheP

olicySelectormenuandenteranewnameinthe

PolicyNamefield,andthenclickRename.
