MACAccessControlLists

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page359

D‐LinkUWSUserManual

IPACLRuleSummary

UsetheIPACLRuleSummarypagetoviewasummaryoftheIPACLsthathavebeenconfiguredontheswitch.

Toaccessthepage,clickLAN>Monitoring>AccessControlLists>IPAccessControlLists>Summary.

Figure244:IPACLRuleSummary

MACAccessControlLists

AMACACLconsistsofasetofruleswhicharematchedsequentiallyagainstapacket.Whenapacketmeets

thematchcriteriaofarule,thespecifiedruleaction(Permit/Deny)istakenandtheadditionalrulesarenot

checkedforamatch.OnthismenutheinterfacestowhichanMA

CACLappliesmustbespecified.Rulesforthe

MACACLarespecified/createdusingtheMACACLRuleConfigurationmenu.

ToconfigureaMACACL:

1. Usethe“MACACLConfiguration”pagetodefinetheACLtypeandassignanIDtoit.

2. Usethe“MACACLRuleConfiguration”pagetocreaterulesforth

eACL.

3. Usethe“ACLInterfaceConfiguration”toassign theACLbyitsIDnumbertoaportorVLAN.
