LocatingWLANDevices

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page637

D‐LinkUWSUserManual

BuildingFloor

UsetheBuildingFloorpagetodefinethefloorswithinthebuildingswhereAPsaredeployed.

Figure410:BuildingFloor

ThefollowingtableshowsthefieldsavailableontheBuildingFloorpage.

CommandButtons

Thepageincludesthefollowingbuttons:

• Delete—Deletestheselectedfloorfromthebuilding.

• DeleteAll—Deletesallconfiguredfloor

sfromthebuilding.

• Refresh—Updatesthepagewiththelatestinformation.

Table373:BuildingFloor

Field Description

BuildingNumber Selectthenumberofthebuildingwiththefloorstodefine.

FloorNumber Uniquenumberfrom1–20thatidentifiesthefloorwithintheselected

building.

FloorDescription Adescriptionusedtoidentifythefloor.Thenamecanbeupto64

characters.ThedefaultdescriptionisNone.

TotalAPCount NumberofAP

sonthefloorwithanadministratively‐configured

physicallocation.
