AssigningPortstoaGroup

1. SelectagroupIDfromtheGroupIDfield.

2. FromtheProtectedPort(s)field,clickoneporttoaddasingleporttothegroup,orholdtheCTRLkeyand

clickmultipleportstoaddmorethanoneporttothegroup.

3. ClickSubmittoapplythechangestothesy

stem.

ProtectedPortsSummary

UsetheProtectedPortsSummarypagetoviewinformationaboutprotectedportgroupsandtheirincluded

ports.

ToviewtheProtectedPortsSummarypage,clickLAN>Monitoring >ProtectedPorts>Summaryinthe

navigationtree.

Figure112:ProtectedPortsSummary

•ClickRefreshtoreloadthepageanddisplaythemostcurrentin

formation.

Table95:ProtectedPortsSummaryFields

Field Description

GroupID IdentifiestheprotectedportsgroupaseitherGroup0,1,or2.

GroupName Identifiestheprotectedportsgroupwithauser‐definedstring.

ProtectedPort(s) ShowstheSlot/Portthataremembersoftheprotectedportsgroup.
