VirtualRouterStatistics

UsetheVirtualRouterStatisticspagetodisplaystatisticsforaspecifiedvirtualrouter.

Todisplaythepage,clickLAN>Monitoring>L3Status>VirtualRouterStatisticsinthenavigationtree.

Figure218showsthefieldsontheVirtualRouterStatisticspageforaswitchthathasoneormor

evirtual

routersconfigured.

Figure218:VirtualRouterStatistics—VirtualRouterConfigured

TheVirtualRouterStatisticspagecontainsthefieldslistedbelow.Manyofthefieldsdisplayonlywhenthere

isavalidVRRPconfiguration.

Table197:VirtualRouterStatisticsFields

Field Description

RouterChecksumErrors ThetotalnumberofVRRPpacketsreceivedwithaninvalidVRRPchecksum

value.

RouterVersionErrors ThetotalnumberofVRRPpacketsreceivedwithanunknownorunsupported

versionnumber.

RouterVRIDErrors ThetotalnumberofVRRPpacketsreceivedwithaninvalidVRIDforthisvirtual

router.

VRIDandSlot/Port Selecttheex

istingVirtualRouter,listedbyinterfacenumberandVRID,for

whichyouwanttodisplaystatisticalinformation.

VRID theVRIDfortheselectedVirtualRouter.
