D-Link DWS-4026 [661/741] Viewing component information

D-Link DWS-4026 [661/741] Viewing component information

VisualizingtheWirelessNetwork

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page661

D‐LinkUWSUserManual

AradiooperatinginSentryModedisplaystheletter“S”inplaceoftheantennaontheAPicon,asFigure431

shows.

Figure431:SentryMode—DetailedView

WhentheAPPowerDisplayisenabled,radiosinsentrymodeshowagrayAPpowerdisplayimagearoundthe

AP.

TheChannelColorlegendmap

sthecolorofthepowerdisplayimagetothechannelthattheimagecolor

represents.Thecolorcorrespondstothechannelthattheradioisusingfortransmission.Theavailable

channelsdependonthemodeandcountryofoperation.

ViewingComponentInformation

Afteryouplaceacomponentonthegraph,youcanright‐clickthecomponenttolearnmoreinformationabout

it,ungraphit,ortoaccessapageontheWebUItomanageormonitorthecomponent.Youmustbeloggedon

totheswitchforthelinkstobeactive.

Figure43

2:WirelessComponentAttributes
