ConfiguringandViewingISDPInformation

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page145

D‐LinkUWSUserManual

ConfiguringandViewingISDPInformation

TheIndustryStandardDiscoveryProtocol(ISDP)isaproprietaryLayer2networkprotocolwhichinter‐operates

withCisco®devicesrunningtheCiscoDiscoveryProtocol(CDP).ISDPisusedtoshareinformationbetween

neighboringdevices.D‐LinkDWS‐4000SeriesswitchesparticipateintheCDPprotocolandareabletoboth

discoverandbedisc

overedbyotherCDPsupportingdevices.

GlobalConfiguration

FromtheISDPGlobalConfigurationpage,youcanconfiguretheISDPsettingsfortheswitch,suchasthe

administrativemode.To displaytheISDPGlobalConfigurationpage,clickLAN>Administration>ISDP>

GlobalConfigurationinthenavigationtree.

Figure71:ISDPGlobalConfiguration

ThefollowingtabledescribesthefieldsavailableontheIS

DPGlobalConfigurationpage.

Table61:ISDPGlobalConfiguration

Field Description

ISDPMode UsethisfieldtoenableordisabletheIndustryStandardDiscoveryProtocolonthe

switch.

ISDPV2Mode UsethisfieldtoenableordisabletheIndustryStandardDiscoveryProtocolv2onthe

switch.

MessageInterval SpecifiestheISDPtransmitinterval.Therangeis(5–254).Defaultvalueis30seconds.

Holdt

imeInterval ThereceivingdeviceholdsISDPmessageduringthistimeperiod.Therangeis(10–255).

Defaultvalueis180seconds.

DeviceID TheDeviceIDadvertisedbythisdevice.TheformatofthisDeviceIDischaracterizedby

thevalueofDeviceIDFormatobject.
