D-Link DWS-4026 [309/741] Route table

Router

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page309

D‐LinkUWSUserManual

•ClickRefreshtoupdatetheinformationonthescreen.

Router

Thepagesaccessiblefr omtheRouterfolderallowyoutoconfiguretheroutingtableandconfigureroute

preferences.

RouteTable

Theroutetablemanagercollectsroutesfrommultiplesources:staticroutes,RIProutes,andlocalroutes.The

routetablemanagermaylearnmultipleroutestothesamedestinationfrommultiplesources.Theroutetable

listsallroutes.Thebestroutestabledisplaysonlythemostpreferredroutetoeachdestination(see“B

est

RoutesTable”onpage311formoreinformation).

Todisplaythepage,clickLAN>Monitoring>L3Status>RouteTableinthenavigationtree.

Figure203:RouteTable

MinimumAdvertise

Interval(secs)

Theminimumtime(inseconds)allowedbetweenrouteradvertisementssent

fromtheinterface.

AdvertiseLifetime(secs) Thevalue(inseconds)usedasthelif

etimefieldinrouteradvertisementssent

fromtheinterface.Thisisthemaximumlengthoftimethattheadvertised

addressesaretobeconsideredasvalidrouteraddressesbyhosts.

PreferenceLevel Thepreferenceleveloftherouterasadefaultrouterrelativetootherrouters

onthesamesubnet.Hi

ghernumberedaddressesarepreferred.

Table183:RouteTableFields

Field Description

TotalNumberofRoutes Thetotalnumberofroutesintheroutetable.

NetworkAddress TheIProuteprefixforthedestination.

SubnetMask Alsoreferredtoasthesubnet/networkmask,thisindicatestheportionofthe

IPinterfaceaddressthatidentifiestheattachednetwork.

Table182:RouterDiscoveryStatusFields(Cont.)

Field Description
