ConfiguringDynamicARPInspection

DynamicARPInspection(DAI)isasecurityfeaturethatrejectsinvalidandmaliciousARPpackets.DAIprevents

aclassofman‐in‐the‐middleattacks,whereanunfriendly stationinterceptstrafficforotherstationsby

poisoningtheARPcachesofitsunsuspectingneighbors.ThemiscreantsendsARPrequestsorresponses

mappinganotherstat

ion’sIPaddresstoitsownMACaddress.

DAIreliesonDHCPsnooping.DHCPsnoopinglistenstoDHCPmessageexchangesandbuildsabindingdatabase

ofvalid{MACaddress,IPaddress,VLAN,andinterface}tuples.

WhenDAIisenabled,theswitchdropsARPpacket swhosesenderMACaddressandsenderIPa

ddressdonot

matchanentryintheDHCPsnoopingbindings database.YoucanoptionallyconfigureadditionalARPpacket

validation.

DAIConfiguration

UsetheDAIConfigurationpagetoconfigureglobalDAIsettings.

TodisplaytheDAIConfigurationpage,clickLAN>L2Features > DynamicARPInspection>DAIConfiguration

inthenavigationtree.

Figure172:DynamicARPInspectionConfiguration

•ClickSubmittoapplythenewconfigurationandcausethechangetotakeeffect.Thesecha

ngeswillnot

beretainedacrossapowercycleunlessaSaveconfigurationisperformed.

Table153:DynamicARPInspectionConfiguration

Field Description

ValidateSource

MAC

SelecttheDAISourceMACValidationModefortheswitch.IfyouselectEnable,Sender

MACvalidationfortheARPpacketswillbeenabled.ThedefaultisDisable.

Validate

DestinationMAC

SelecttheDAIDestinationMACValidationModefortheswitch.IfyouselectEnable,

DestinationMACvalidationfo

rtheARPResponsepacketswillbeenabled.Thedefaultis

Disable.

ValidateIP SelecttheDAIIPValidationModefortheswitch.IfyouselectEnable,IPAddressvalidation

fortheARPpacketswillbeenabled.ThedefaultisDisable.
