MultiplePortMirroring

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page87

D‐LinkUWSUserManual

AddingaPortMirroringSession

1. FromtheLAN>Administration>MultiplePortMirroringpage,clickAddSourcePorttodisplaytheAdd

SourcePortpage.

Figure26:MultiplePortMirroring—AddSourcePorts

2. Configurethefollowingfields:

3. ClickAddtoapplythechangestothesystem.

Thenewportmirroringsessionise nabledfortheunitandport,andthedeviceisu

pdated.Thesourceport

appearsintheSourcePortlistontheMultiplePortMirroringpage.

Note:APortwillberemovedfromaVLANorLAGwhenitbecomesadestinationmirror.

Table19:MultiplePortMirroring—AddSourceFields

Field Description

Session Specifiesthemonitoringsession.

SourcePort Selecttheunitandportfromwhichtrafficismirrored.Uptoeightsourceports

canbemirroredtoadestinationport.

Direction Selectthetypetrafficmonitoredonthesourceport,whichcanbeoneofthe

following:

• Tx:Monitorstransmittedpacketsonly.

• Rx:Monitorsre

ceivedpacketsonly.

• TxandRx:Monitorstransmittedandreceivedpacket s.
