MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page438

D‐LinkUWSUserManual

TouseoneormoreswitchesasabackupforanAP,useoneofthefollowingdiscoverymethods:

•IftheAPandanyofthepeerswitchesareinthesameL2broadcastdomain,L2Discoveryisenabled,and

allthedevicesusethedefaultVLANsettings,apeerswitchwillaut

omaticallydiscovertheAPifthe

primaryDWS‐4000Seriesswitchbecomesunavailable.

• ConfiguretheIPaddressoftheAPinmultipleswitches.

• ConfiguretheIPaddressofuptofourswitchesintheAPwhileitisinStandaloneMode.

• ConfiguretheDHCPoption43withtheIPaddressesofadditionalsw

itchesinthecluster.

MonitoringStatusandStatistics

TheStatus/Statisticsfoldercontainslinkstothefollowingpagesthathelpyoumonitorthestatusandstatistics

foryourD‐LinkUnifiedSwitchnetwork:

• MonitoringStatusandStatistics

• ManagedAPStatus

• AssociatedClientStatus/Statistics

• PeerSwitchStatus

• RadioResourceMeasurementStatusInformation

WirelessGlobalStatus/Statistics

TheDWS‐4000SeriesswitchperiodicallycollectsinformationfromtheAPsitmanagesandfromassociated

peerswitches.TheinformationontheGlobalpageshowsstatusandstatisticsabouttheswitchandallofthe

objectsassociatedwithit.YoucanaccesstheglobalWLANstatisticsbyclickingWLAN>Monitoring>Global.
