IPInterfaceConfiguration

UsetheIPInterfaceConfigurationpagetoupdateIPinterfacedataforthisswitch.

Todisplaythepage,clickLAN>L3Features>IP>InterfaceConfigurationinthenavigationtree.

Figure189:IPInterfaceConfiguration

Table171:IPInterfaceConfigurationFields

Field Description

Interface Selecttheinterfacetoconfigurefromthedropdownmenu.Thedropdown

menucontainslogicalinterfaces,includingloopbackinterfacesandVLAN

routinginterfaces.

RoutingInterfaceStatus ShowswhethertheIPv4routingisupordownontheinterface.

IPAddressConfiguration

Method

SpecifywhethertheselectedinterfaceshouldreceiveanIPaddress

dynamicallythr

oughDHCP,orstaticallythroughmanualIPaddress

assignment.

IfyouconfigureDHCPasthemethod,additionalbuttonsdisplayatthebottom

ofthepagethatallowyoutorenew,release,ordisplayDHCP‐assigned

information.

IPAddress Iftheconfigurationmethodismanual,enterthestaticIP addressforthe

interface.

SubnetMask Ifthec

onfigurationmethodismanual,enterthesubnetmaskfortheinterface.

Thisisalsoreferredtoasthesubnet/networkmask,anddefinestheportionof

theinterface'sIPaddressthatisusedtoidentifytheattachednetwork.
