D-Link DWS-4026 [179/741] Mac address table

ConfiguringandSearchingtheForwardingDatabase

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page179

D‐LinkUWSUserManual

MACAddressTable

UsetheMACAddressTablepagetodisplayinformationaboutentriesintheforwardingdatabase.

Toaccessthepage,clickLAN>Monitoring>MACAddressTableinthenavigationtree.

Figure95:ForwardingDatabaseSearch

Table79:ForwardingDatabaseSearchFields

Field Description

Filter Specifythetypeofentriestodisplay.Whenyouselectafilterfromthemenu,

thescreenrefreshesanddisplaystheentriesbasedonthefilteryouselect,

whichcanbeoneofthefollowing:

• Learned:IfyouselectLearned,onlyMACaddr essesthathavebeen

learnedaredisplayed.

• All:Ifyo

uselectAll,theentiretableisdisplayed.

MACAddressSearch ThisfieldallowsyoutosearchforanindividualMACaddressintheforwarding

databasetable.

MACAddress AunicastMACaddressforwhichtheswitchhasforwardingand/orfiltering

information.TheformatisatwobytehexadecimalVLANIDnu

mberfollowed

byasixbyteMACaddresswitheachbyteseparatedbycolons.Forexample:

01:23:45:67:89:AB:CD:EF,where01:23istheVLANIDand45:67:89:AB:CD:EF

istheMACaddress.

SourceSlot/Port(s) Theportwherethisaddresswaslearned.Inotherwords,thisfieldshowsthe

portthroughwhichtheMACaddresscanber

eached.

ifIndex TheifIndexoftheMIBinterfacetableentryassociatedwiththesourceport.

Status Thestatusofthisentry.Thepossiblevaluesare:

• Static:TheentrywasaddedwhenastaticMACfilterwasdefined.

• Learned:TheentrywaslearnedbyobservingthesourceMACaddressesof

incomingtraffic,andiscu

rrentlyinuse.

• Management:ThesystemMACaddress,whichisidentifiedwithinterface

0.1.

• Self:TheMACaddressofoneoftheswitch'sphysicalinterfaces.
