ConfiguringRIP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page305

D‐LinkUWSUserManual

RIPRouteRedistri butionConfiguration

UsetheRIPRouteRedistributionConfigurationpagetoconfigurewhichroutesareredistributedtoother

routersusingRIP.Theallowablevaluesforeachfieldsaredisplayednexttothefield.Ifanyinvalidvaluesare

entered,analertmessageisdisplayedwiththelistofallthevalidvalues.

Todisplaythepa

ge,clickLAN>L3Features>RIP>RouteRedistributionConfigurationinthenavigationmenu.

Figure199:RIPRouteRedistributionConfiguration

YouconfigureACLsthroughthepagesunderLAN>AccessControlLists > IPAccessControlLists.Whenused

forroutefi ltering,theonlyfieldsinanaccesslisttha

tgetusedare:

•SourceIPAddressandnetmask

•DestinationIPAddressandnetmask

• Action(PermitorDeny)

Allotherfields(sourceanddestinationport,precedence,ToS,etc.)areignored.

Table179:RIPRouteRedistributionConfigurationFields

Field Description

ConfiguredSource IfanySourceRouteshavealreadybeenconfiguredforredistributionbyRIP,

theyappearinthedropdownmenu.Otherwise,theonlyavailableoptionis

Create,whichallowsyoutoconfigureanavailablesourceroute.Selectan

existingroutetoviewormodifyitsparameters.

AvailableSource Thedropdownmenuispopulatedbyonlytho

seSourceRoutesthathavenot

previouslybeenconfiguredforredistributionbyRIP.Thisfieldisavailableonly

ifyouselectCreateastheConfiguredSource.Possiblevaluesare:

•Static:Theroutewasmanuallyconfigured.

• Connected:Theroutewasdeterminedautomaticallybecausethehostis

directlyconnected.

•RIP:Theroutewasdet

erminedthroughRIP.

Metric Setsthemetricvaluetobeusedasthemetricofredistributedroutes.Thisfield

displaysthemetricifthesourcewaspre‐configuredandcanbemodified.The

validvaluesare1to15.

DistributeList EntertheACLIDforanaccesslistthatfiltersthero

utestoberedistributedby

thedestinationprotocol.Onlypermittedroutesareredistributed.
