DiffServPolicyAttributeSummary

TheDiffServPolicyAttributeSummarypageprovidesanoverviewoftheattributesthathavebeenconfigured

foreachpolicy.To displaythepage,clickLAN>Monitoring>DifferentiatedServices>PolicyAttribute

Summaryinthenavigationmenu.

Figure233:PolicyAttributeSummary

ServiceConfiguration

UsetheServiceConfigurationpagetoactivateapolicyonaport.

Todisplaythepage,clickLAN>QoS>DifferentiatedServices> ServiceConfigurationinthenavigationmenu.

Figure234:ServiceConfiguration

Toactivateapolicyonaninterface,selecttheinterfaceandthepolicy,andthenclickSubmit.

Table207:Ser

viceConfigurationFields

Field Description

Interface Selectstheinterface(physical,LAG,orAll)tobeaffectedfrommenus.Thisis

alistofallvalidslotnumberandportnumber combinationsinthesystem,

includingallinterfaces.

PolicyIn Thislistsallthepolicynamesoftype‘In’tobeassociatedwiththeportwhich

canbese

lectedfromamenu.If‘None’isselected,thiswilldetachthepolicy

fromtheinterfaceinthisdirection.

Direction ThisfielddisplaysonlywhenAllisselecte dfromtheInterfacemenu.Selectthe

trafficdirectionofthisserviceinterface.
