D‐LinkUWSUserManual

MulticastRouterVLANStatus

UsetheMLDSnoopingMulticastRouterVLANStatuspagetoviewmulticastroutersettingsforVLANsona

specificinterface.

ToaccesstheMLDSnoopingMulticastRouterVLANStatisticspage,clickMonitoring>MLDSnooping>

MulticastRouterVLANStatusinthenavigationtree.

Figure139:MLDSnoopingMulticastRouterVLANStatus

TheMLDSnoopi

ngMulticastRouterVLANStatisticspagecontainsthefollowingfields:

•ClickRefreshtore‐displaythepagewiththelatestinformationfromtherouter.

Table121:MLDSnoopingMulticastRouterVLANStatusFields

Description

Slot/Port SelectthephysicalorLAGinterfacetodisplay.

VLANID IfaVLANisenabledformulticastroutingontheinterface,thisfielddisplaysitsID.

MulticastRouter IndicatesthatthemulticastrouterisenabledfortheVLANonthisinterface.
