PeerSwitch

ThePeerSwitchConfigurationfeatureallowsyoutosendavarietyofconfigurationinformationfromone

switchtoallotherswitches.Inadditiontokeepingtheswitchessynchronized,thisfunctionallowsyouto

manageallwirelessswitchesintheclusterfromoneswitch.ThePeerSwitchConfigurationRequestStatus

pageprovidesin

formationaboutthestatusoftheconfigurationupgradeontheswitchesinthecluster.

Figure393:PeerSwitchConfigurationRequestStatus

Toinitiateaconfigurationupdateonaspecificpeer switch,selecttheboxnexttotheIPaddressofthepeer

switchtoupdate,andthenclickStart.Toupdateallpeers

witches,clickStartAll.

ThefollowingtabledescribesthefieldsonthePeerSwitchConfigurationRequestStatuspage.

Table357:PeerSwitchConfigurationRequestStatus

Field Description

ConfigurationRequestStatus Indicatestheglobalstatusforaconfigurationpushoperationtooneor

morepeerswitches.Thestatuscanbeoneofthefollowing:

•NotStarted

•ReceivingConfiguration

• SavingConfiguration

•Success

• Failure—InvalidCodeVersion

• Failure—InvalidHardwareVersion

• Failure—InvalidConfiguration

TotalCount Indicatesthenumberofpeerswitchesincludedatthetimea

configurationdownloadr

equestisstarted,thevalueis1ifadownload

requestisforasingleswitch.

SuccessCount Indicatesthetotalnumberofpeerswitchesthathavesuccessfully

completedaconfigurationdownload.

FailureCount Indicatesthetotalnumberofpeerswitchesthathavefailedto

completeaconfigurationdownload.

PeerIPAddress Liststh

eIPaddressofeachswitchintheclusterandindicatesthe

configurationrequeststatusofthatswitch.
