Statistics

UsetheLLDPStatisticspagetoviewtheglobalandinterfaceLLDPstatistics.

TodisplaytheLLDPStatisticspage,clickLAN>Monitoring>LLDPStatus > Statisticsinthenavigationtree.

Figure162:LLDPStatistics

Table143:LLDPStatisticsFields

Field Description

System‐wideStatistics

LastUpdate Displaysthetimewhenanentrywascreated,modified,ordeletedinthetables

associatedwiththeremotesystems.

TotalInserts Displaysthenumberoftimesacompletesetofinformationadvertisedbyaparticular

MACServiceAccessPoint(MSAP)hasbeeninsertedintothetablesassociatedwiththe

motesystems.

TotalDeletes Displaysthenumberoftimesacompletesetofinformationadvertisedbyaparticular

MACServiceAccessPoint(MSAP)hasbeendeletedfromthetablesassociatedwiththe

remotesystems.

TotalDrops Displaysthenumberoftimesacompletesetofinformationadvertisedbyaparticular

MACServiceAcce

ssPoint(MSAP)couldnotbeenteredintotablesassociatedwiththe

remotesystemsbecauseofinsufficientresources.

TotalAgeouts Displaysthenumberoftimesacompletesetofinformationadvertisedbyaparticular

MACServiceAccessPoint(MSAP)hasbeendeletedfromtablesassociatedwiththe

remotesystemsbecausethei

nformationtimelinesintervalhasexpired.

PortStatistics

Interface Displaystheslot/portfortheinterfaces.

TransmitTotal DisplaysthetotalnumberofLLDPframestransmittedbytheLLDPagentonthe

correspondingport.

ReceiveTotal DisplaysthetotalnumberofvalidLLDPframe sreceivedbytheLLDPagentonthe

correspondingport,whiletheLLDPagentisenabled.

Discards Displaysthenu

mberofLLDPTLVsdiscardedforanyreasonbytheLLDPagentonthe

correspondingport.
