WDSAPLinkStatusSummary

TheWDSAPLinkStatusSummarypagedisplayssummaryinformationaboutthelinkconfigurationandlink

stateinaWDSgroup.

Figure355:WDSAPLinkStatusSummary

ThefollowingtabledescribesthefieldsontheWDSAPLinkStatusSummarypage.

Note:TheWDSlinksarebidirectional.ThetermsSourceandDestinationsimplyreflecttheWDSlink

endpointsspecifiedintheWDSgroupconfiguration.

Table321:WDSAPLinkStatusSummary

Field Description

WDSAPGroupID ThegroupnumberthatidentifiestheconfiguredWDSAPgroup.

SourceMACAddress TheMACaddressofoneend‐pointoftheWDSlink

RadioSource TheradionumberoftheWDSlinkendpointonthesourceAP.

DestinationMAC

Address

TheMACaddressoftheSourceAPinthegr

oup.

DestinationRadio TheradionumberoftheWDSlinkendpointonthedestinationAP.

SourceEnd‐Point

Detected

IndicateswhethertheAPspecifiedbythedestinationMACdetectedtheAPspecified

bythesourceMAC.

DestinationEnd‐Point

Detected

IndicateswhethertheAPspecifiedbythesourceMACdetectedtheAPspecifiedby

thede

stinationMAC.

AggregationMode Whenparallelli nksaredefinedbetweentwoAPs,thisfieldindicateswhetherthislink

ispartoftheaggregationlinkpair.
