ManagingVLANs

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page183

D‐LinkUWSUserManual

VLANPortConfiguration

UsetheVLANPortConfigurationpagetoconfigureavirtualLANonaport.

ToaccesstheVLANPortConfigurationpage,clickLAN>L2Features >VLAN>PortConfigurationinthe

navigationtree.

Figure98:VLANPortConfiguration

•Ifyouchangeanyinformationonthepage,clickSubmittoapplythechange

stothesystem.

Table82:VLANPortConfigurationFields

Field Description

Slot/Port Selectthephysicalinterfaceforwhichyouwanttodisplayorconfiguredata.

SelectAlltosettheparametersforallportstosamevalues.

PortVLANID SpecifytheVLANIDyouwantassignedtountaggedorprioritytaggedframes

receivedonthisport.Thefactorydefaultis1.

AcceptableFrameTy

pes Specifyhowyouwanttheporttohandleuntaggedandprioritytaggedframes.

Whicheveryouselect,VLANtaggedframeswillbeforwardedinaccordance

withtheIEEE802.1QVLANstandard.ThefactorydefaultisAdmitAll.

• VLANOnly:Theportwilldiscardanyuntaggedorprioritytaggedframesit

receives.

• AdmitAll:Un

taggedandprioritytaggedframesreceivedontheportwill

beacceptedandassignedthevalueofthePortVLANIDforthisport.

IngressFiltering Specifyhowyouwanttheporttohandletaggedframes:

• Enable:Ataggedframewillbediscardedifthisportisnotamem

berofthe

VLANidentifiedbytheVLANIDinthetag.

• Disable:Alltaggedframeswillbeaccepted.Thefactorydefaultisdisable.

PortPriority Specifythedefault802.1ppriorityassignedtountaggedpacketsarrivingatthe

port.
