•ClickRefreshtoupdatetheinformationonthescreenwiththemostcurrentdata.

LocalDeviceSummary

UsetheLLDPLocalDeviceSummarypagetoviewinformationaboutallinterfacesonthedevicethatare

enabledtotransmitLLDPinformation.

TodisplaytheLLDPLocalDeviceSummarypage,clickLAN>Monitoring>LLDPStatus> LocalDeviceSummary

inthenavigationtree.

Figure164:LLDPLocalDeviceSummary

Table144:LL

DPLocalDeviceInformationFields

Field Description

Interface SelectfromthelistofalltheportsonwhichLLDP‐802.1ABframescanbe

transmitted.

ChassisIDSubtype Displaysthestringthatdescribesthesourceofthechassisidentifier.

ChassisID Displaysthestringvalueusedtoidentifythechassiscomponentassociated

withthelocalsystem.

PortIDSubtype Displaysthestringde

scribingthesourceoftheportidentifier.

PortID Identifiesthephysicaladdressoftheport.

SystemName Displaysthesystemnameofthelocalsystem.

SystemDescription Displaysthedescriptionoftheselectedportassociatedwiththelocalsystem.

PortDescription Displaystheuser‐defineddescriptionoftheport.

SystemCapabilities

Supported

Displaysthesy

stemcapabilitiesofthelocalsystem.

SystemCapabilitiesEnabled Displaysthesystemcapabilitiesofthelocalsystemwhicharesupportedand

enabled.

ManagementAddress Displaystheadvertisedmanagementaddressofthelocalsystem.

ManagementAddressType Specifiesthetypeofthemanagementaddress.
